A narrow forward beam can leave the sides of a trail outside the lighted area. Adding separate wide lights is one way to cover those areas. Universal fit - not built for one specific make or model, so confirm mounting space and wiring on your machine before ordering. Integrated Peripheral Technology spreads usable LED light across 200 degrees, while the forward optics provide a choice of Driving/Combo or Spot beams. Direct Ducted Cooling circulates air over the rear heat sinks.
Key Features
11,225 lumens and a 200-degree spread of usable LED light
Driving/Combo optics blend 42-degree driving and 8-degree spot beams
Spot pattern concentrates light in an 8-degree beam for longer reach
High-beam, low-beam and daytime running backlight modes
Direct Ducted Cooling directs air over the rear heat sinks
Replaceable lenses and optics through the uService design
IP69K water-resistance rating and IK10 impact-resistance compliance
Built To Solve: LP6 Pro Forward and Peripheral Lighting
Light near-field and distant areas with the Driving/Combo beam.
Choose the Spot beam to focus light farther down a trail or road (where permitted).
Spread usable light to the sides through Integrated Peripheral Technology.
Select high-beam, low-beam or daytime running backlight modes.
Best For: Riders Choosing Auxiliary LED Pod Lights
Riders looking for a universal pod rather than a vehicle-specific light kit.
Trail riders choosing a blend of near-field and distance lighting.
Buyers adding a narrow spot beam alongside wider auxiliary lights.
Show builds using red, blue or green backlighting for exhibition use.
Specifications
Light output: 11,225 lumens
Usable light spread: 200 degrees
Dimensions: 6.5 inches high × 6.5 inches long × 3.2 inches deep
Weight: 4.2 lb
Wattage: 103.5 W
Amperage: 7.5 A
Water resistance: IP69K; waterproof up to 9 feet and pressure washable
Impact resistance: IK10 compliant
Housing material: Powder-coated cast aluminum
Lens material: Hardcoated polycarbonate
Connector: DT06-4S Deutsch
Light quantity: 1 pod
What's in the Box
Stainless steel mounting hardware
Fitment
Universal; no vehicle-specific fitment
Fitment is based on current product data for this part and is not guaranteed on unlisted applications. If you don't see your exact setup, contact us and we'll confirm fitment before you order.
FAQ
How do I choose between Driving/Combo and Spot?
Choose Driving/Combo for a blend of near-field and distance coverage. Choose Spot for a longer, narrower beam.
How wide is the LP6 Pro's usable light spread?
Baja Designs rates the usable LED light spread at 200 degrees.
What connector does the light use?
The listed terminal connector is a DT06-4S Deutsch.
Does the light come with a wiring harness?
No. The wiring harness is not supplied.
Will this fit my machine?
Universal fit - not built for one specific make or model. Fitment is not guaranteed on unlisted applications, so confirm mounting space and wiring on your machine before ordering.
Why Baja Designs
Baja Designs uses Integrated Peripheral Technology for a 200-degree spread and Direct Ducted Cooling to circulate air over the LP6 Pro's rear heat sinks.
Choose Your Baja Designs LP6 Pro Light Pod
Select a beam pattern, lens color and backlight option for your LP6 Pro.
